18 EB 8091-1 EN
Design and principle of operation
Dimensional drawings
L
L1
SW50
57
SW46
L1
H4H2
H1
Type3510 as angle valve with
female thread
Type3510 as globe valve with
female thread, with bellows seal or insulat-
ing section
