EB 8091-1 EN 17
Design and principle of operation
Connection
Female
thread
Welding ends Flanges
G/NPT/
Rc
1
/
8
to ¾
NPS½ NPS1 NPS½ NPS¾ NPS1
H1 120cm²
in 4.80
mm 122
H4
Insulating section
up to Class 2500
10.35”/263mm
Bellows seal up to
Class 600
10.35”/263mm
Bellows seal up to
Class 1500
14.37”/365mm
H2 or
ange Ø
D1
Class 150
in
0.90”
2)
23mm
2)
0.90”
2)
23mm
2)
0.90”
2)
23mm
2)
3.54 3.94 4.33
mm 90 100 110
Class 300
in 3.74 4.53 4.91
mm 95 115 125
Class 600
in 3.74 4.53 4.91
mm 95 115 125
Class900/
Class1500
in 4.72 5.12 5.91
mm 120 130 150
Class 2500
in 5.31 5.51 6.30
mm 135 140 160
1)
Face-to-face dimensions of anges according to DINEN558
2)
H2= 1.10” (28mm) with body material B574 N06455
