Adjusting the set point
4.5 Rotating supplementary
lter
The rotating supplementary lter (Fig.14) is
designed for mounting to Type4708-53 and
Types4708-55 to -64 Supply Pressure Regu-
lators. It replaces the small integrated lter
cartridge. The entire lter housing can be ro-
tated by 360° to ensure that the condensate
drain is always facing downwards.
Filter versions
Aluminum body with lter in transparent
plastic receptacle
Temperature range: –25 to +70°C,
order no. 1400-9460
Specialversion:
Temperature range: –50 to +70°C,
Order no. 1400-9461
4.5.1 Mounting the rotating
supplementarylter
1. Remove the cover and lter cartridge
from the supply pressure regulator.
2. Place the supplied seal carefully onto the
groove (see arrow) of the connection.
3. Insert connecting pipe together with seal
into the supply pressure regulator and
tighten the plastic coupling nut.
Î Make sure that the seal does not fall out
of the groove on mounting.
4. Adjust the direction of the supplementary
lter until it is upright.
5. Secure the position by tightening the
hexagonal socket screw (6mm).
Fig.18:Connection and seal for supplementary
lter
5 Adjusting the set point
Î Refer to Fig.2
Î Unscrew the cap (5) on the set point
screw (7) and adjust the set point of the
supply pressure regulator.
Î Turning the knob or screw clockwise in-
creases the output pressure and turning it
counterclockwise reduces the output pres-
sure.
Î Lock the setting with the lock nut (8).
