Samsung DV409SEL - Page 47

Exploded views and Parts list _ 45
MODEL CODE: DV409SEL/XAC
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Drawing
No.
Code No. Description Specification QTY Un SA/SNA
0 DC97-14816A ASSY DRUM DV438AEG/XAA,PURPLE DRYER,-,-, 1 PC SNA
1 DC61-01521A CASE-FILTER DV736E4/XAA(FRONTIER),FRPP(G 1 PC SA
2 DC61-01522A DIE-RACK DRY FRONTIER-DRYER,TB-53,-,-,NT 1 PC SA
3 DC97-07526B ASSY DUCT OUTLET DV337AEW,DRYER/BRACKET- 1 PC SA
3-1 6041-001035 RIVET-RH K1661-0512,AL(A5052),OD3.9,L11, 2 PC SNA
3-2 DC61-01667A BRACKET-FILTER(U) MDE9700AYW,GI,T1.0,-,- 1 PC SNA
3-3 DC63-10001K SPONGE-EPDM SWF-P12,EPDM,-,T3,W15,L530,B 1 PC SNA
3-4 DC67-00127A DUCT-OUTLET(F) WINGS-DRYER,GI,T0.35,-,-, 1 PC SNA
3-5 DC67-00128B DUCT-OUTLET(B) DV337AEW,GI,T0.6,-,-,NTR, 1 PC SNA
3-6 DC72-00032A SPONGE-EPDM MDE9700AYW,EPDM,-,T5,W20,L40 1 PC SNA
3-7 DC72-00032C SPONGE-EPDM MDE9700AYW,EPDM,-,T5,W20,L38 1 PC SNA
4 DC97-10354A ASSY DRUM FRONT DV736E4/XAA,FRONTIER-DRY 1 PC SNA
4-1 DC47-00021A SOCKET-LAMP -,MDE7800,E12,125V,0.6A,-,12 1 PC SA
4-2 DC60-50145A NUT-HEX -,MSWR10,-,-,-,-,-,-,M10 2 PC SA
4-3 DC60-60060A WASHER -,T2,-,ID12,OD24,-,YEL,- 4 PC SA
4-4 DC61-01220A GUIDE-LAMP 27-DRYER,FH44N,-,-,-,BLK,INTE 1 PC SA
4-5 DC63-00531A COVER-LAMP WINGS-DRYER,PC(LEXAN#141R),-, 1 PC SA
4-6 DC63-00538A COVER-FILTER(F) WINGS-DRYER,TI-42,-,-,-, 1 PC SA
4-7 DC63-00675A COVER-FILTER(B) DV736E4/XAA,TI-42,-,-,-, 1 PC SA
4-8 DC97-10362A ASSY-S.DRUM FRONT DV736E4/XAA,FRONTIER-D 1 PC SA
4-9 DC97-07523B ASSY ROLLER -,27-DRYER,DRYER/EPDM,-,-,- 2 PC SA
4-9-1 DC61-01228A HOLDER-SHAFT WINGS-DRYER,NYLON#6,-,-,-,N 2 PC SA
4-10 4713-001199 LAMP-INCANDESCENT 120V,83mA,10W,NTR,-,-, 1 PC SA
4-11
DC97-08894A ASSY GUIDE SENSOR(M) MDE9700AYW,TOUCH SE 1 PC SNA
4-11-1
DC96-00766A ASSY WIRE HARNESS GR-PJT,-,-,SUB/TOUCH S 1 PC SA
4-11-2
DC97-08889A ASSY GUIDE SENSOR MDE9700AYW,YOUCH SENSO 1 PC SA
4-11-2-1
DC61-01231A PLATE-SENSOR 27-DRYER,STS304,T0.8,-,-,-, 2 PC SA
4-11-2-2
DC61-01235A GUIDE-SENSOR WINGS-DRYER,TI-42,-,-,-,GRY 1 PC SA
5 DC97-14849A ASSY DRUM WRAPPER DV438AEG/XAA,STS430J1L 1 PC SA
5-1 DC66-00397C DRUM-WRAPPER 27-DRYER,STS430,625.3,OD667 1 PC SNA
5-2 DC66-00511A DRUM-LIFTER DV448AEW/XAA,PP-TI42,-,-,455 3 PC SA
5-3 DC97-07618A ASSY GASKET PAD MDE9700AYW,DRYER/DRUM-WR 2 PC SNA
6 DC97-14999C ASSY DRUM BACK DV448AEW/XAA,PURPLE-PJT(E 1 PC SNA
6-1 DC60-50145A NUT-HEX -,MSWR10,-,-,-,-,-,-,M10 2 PC SA
6-2 DC60-60060A WASHER -,T2,-,ID12,OD24,-,YEL,- 4 PC SA
6-3 DC61-01237A BRACKET-DRUM BACK WINGS-DRYER,SBHG1-A,T0 1 PC SNA
6-4 DC61-01238A BRACKET-DRUM BACK 27-DRYER,SBHG1-A,T0.8, 2 PC SNA
6-5 DC61-02063A GUIDE-NOZZLE DV448AEG/XAA,PP(T142),T2.5, 1 PC SA
