Samsung DV409SEL - Page 48

46 _ Exploded views and Parts list
MODEL CODE: DV409SEL/XAC
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Drawing
No.
Code No. Description Specification QTY Un SA/SNA
6-6 DC63-00907A COVER-VALVE WATER DV448,PP,T2.5,W109.7, 1 PC SA
6-7 DC66-00398G DRUM-BACK DV448AEW/XAA,STS445NF,T0.6,-,- 1 PC SA
6-8 DC97-07521A ASSY DUCT AIR MDE7800AYW,DRYER,-,-,ELECT 1 PC SA
6-9 DC97-07523B ASSY ROLLER -,27-DRYER,DRYER/EPDM,-,-,- 2 PC SA
6-9-1 DC61-01228A HOLDER-SHAFT WINGS-DRYER,NYLON#6,-,-,-,N 2 PC SA
6-10 DC97-14929A ASSY STEAM KIT DV448AEG,100cc/min,120V/6 1 PC SA
6-10-1 DC62-30042A VALVE-WATER DV448,PA66,80.8*97.6*44.7,0. 1 PC SA
6-10-2 DC67-00331A HOSE-DRAWER DV448AEW,NYLON,ID4.3,OD6.35, 0.597 M SNA
6-10-3 DC97-14928A ASSY ELBOW DV448AEG/XAA,C3604,-,-,- 1 PC SNA
6-10-4 DC97-14931A ASSY NOZZLE DV448AEG/XAA,-,-,-,-,NICKEL 1 PC SNA
