Installer reference guide / Mono tank integrated type 149
3) #504* : Power Peak Control
10** | Remote Controller
101* | Water Out Temp. for Cool
102* | Room Temp. for Cool
103* | Water Out Temp. for Heat
104* | Room Temp. for Heat
105* | DHW Tank Temp.
20** | Water Law
201* | Outdoor Temp. for Water Law
202* | Water Out Temp. for WL1 Heat
203* | Water Out Temp. for WL2 Heat
2041 | Heating Water Law for Auto Mode
205* | Outdoor Temp. for Water Law
206* | Water Out Temp. for WL1 Cool
207* | Water Out Temp. for WL2 Cool
30** | DHW
301* | Domestic Hot Water Tank
302* | Heat Pump
303* | Booster Heat
304* | Disinfection
305* | Forced DHW Operation
306* | Solar Panel/DHW Thermostat
307* | Direction of 3Way Valve
308* | Energy Metering
50** | Others
501* | Outing
502* | DHW Saving
503* | TDM Variable (TDM Product only)
504* | Power Peak Control
5051 | Frequency Ratio Control
5061 | Heat/DHW Capa. Ratio
508* | PV Control
509* | Smart Grid Control
50** | Others
501* | Outing
502* | DHW Saving
503* | TDM Variable (TDM Product only)
504* | Power Peak Control
5051 | Frequency Ratio Control
5061 | Heat/DHW Capa. Ratio
508* | PV Control
509* | Smart Grid Control
50** | Others
501* | Outing
502* | DHW Saving
503* | TDM Variable (TDM Product only)
504* | Power Peak Control
5051 | Frequency Ratio Control
5061 | Heat/DHW Capa. Ratio
508* | PV Control
509* | Smart Grid Control
50** | Others
501* | Outing
502* | DHW Saving
503* | TDM Variable (TDM Product only)
504* | Power Peak Control
5051 | Frequency Ratio Control
5061 | Heat/DHW Capa. Ratio
508* | PV Control
509* | Smart Grid Control
5014 | Room Temp. for Heat
5015 | Auto Cooling WL1 Temp.
5016 | Auto Cooling WL2 Temp.
5017 | Auto Heating WL1 Temp.
5018 | Auto Heating WL2 Temp.
5019 | Target Tank Temp.
40** | Heat
401* | Heat Pump
402* | Backup Heater
403* | Backup Boiler
404* | Mixing Valve
405* | Inverter Pump
406* | Zone Control
401* | Heat Pump
4011 | Heat/DHW Priority
4012 | Outdoor Temp. for Priority
4013 | Heat OFF(Outdoor Ambient Temp.)
40** | Heat
401* | Heat Pump
402* | Backup Heater
403* | Backup Boiler
404* | Mixing Valve
405* | Inverter Pump
406* | Zone Control
402* | Heat Pump
4021 | Application
4022 | Backup Heater/Booster Heater Priority
4023 | Cold Weather Compensation
4025 | Defrost Backup Temp.
4024 | Threshold Temp.
40** | Heat
401* | Heat Pump
402* | Backup Heater
403* | Backup Boiler
404* | Mixing Valve
405* | Inverter Pump
406* | Zone Control
403* | Backup Boiler
4031 | Application
4032 | Boiler Priority
4033 | Threshold Temp.
40** | Heat
401* | Heat Pump
402* | Backup Heater
403* | Backup Boiler
404* | Mixing Valve
405* | Inverter Pump
406* | Zone Control
404* | Mixing Valve
4041 | Application
4042 | Target △T(Heating)
4043 | Target △T(Cooling)
4044 | Control Factor
4045 | Control Interval
4046 | Running Time
501* | Outing
5011 | Water Out Temp. for Cool
5012 | Room Temp. for Cool
5013 | Water Out Temp. for Heat
502* | DHW Saving
5021 | DHW Saving Temp.
5022 | DHW Saving Mode
5023 | DHW Saving Thermo on Temp.
503* | TDM Variable(TDM Product only)
5031 | Priority Max. Operation Time
5032 | Non Priority Min. Operation Time
5033 | A2A/DHW Priority
504* | Power Peak Control
5041 | Application
5042 | Select Forced Off Parts
5043 | Using Input Voltage
50** | Others
501* | Outing
502* | DHW Saving
503* | TDM Variable (TDM Product only)
504* | Power Peak Control
5051 | Frequency Ratio Control
5061 | Heat/DHW Capa. Ratio
508* | PV Control
509* | Smart Grid Control
509* | Smart Grid Control
5091 | Application
5092 | Setting Temp. Shift Value(Heat)
5093 | Setting Temp. Shift Value(DHW)
5094 | DHW Mode
50** | Others
501* | Outing
502* | DHW Saving
503* | TDM Variable (TDM Product only)
504* | Power Peak Control
5051 | Frequency Ratio Control
5061 | Heat/DHW Capa. Ratio
508* | PV Control
509* | Smart Grid Control
508* | PV Control
5081 | Application.
5082 | Setting Temp. Shift Value(Cool)
5083 | Setting Temp. Shift Value(Heat)
50** | Others
501* | Outing
502* | DHW Saving
Use
503* | TDM Variable (TDM Product only)
504* | Power Peak Control
5051 | Frequency Ratio Control
5061 | Heat/DHW Capa. Ratio
508* | PV Control
509* | Smart Grid Control
5051 | Frequency Ratio Control
5051 | Water Out Temp. for Cool
Main Menu
(FSV)
Sub Menu
Function
Description FSV Step Unit
Default
Min. Max.
Others
FSV 50**
Power Peak
Control
Application 5041 - - 0 (No) 0 1 (Yes)
Select Forced Off Parts 5042 1 - 0 (All) 0 3
Using Input Voltage 5043 - - 1 (High) 0 (Low) 1
• Depending on the local situation, a power company can limit the amount of power consumed by consumers during a
• The default setting for FSV (#5041) is value 0 (No, no application of the Power Peak Control).
• If FSV(#5041) setting "1", compressor, backup heater, booster heater operate according the below table:
#5042 Compressor Backup heater Booster heater
0 (Default) Permitted Forced off Permitted
1 Permitted Forced off Forced off
2 Forced off Forced off Permitted
3 Forced off Forced off Forced off
• The default input type is a high signal (voltage applied).
• In exceptional situations it is required to change to low input, depending on the demands of the (local) power
• When the input signal is applied, the system goes into "Thermo off" for all operations (as indicated by FSV (#5042)).
• If the EHS system is not operable for a long time (>60min) by applying the Power Peak Control, the usage of glycol is
advised during subzero ambient conditions. Please check the terms and conditions of the (local) power company.
