9. Commissioning & Recommissioning
Installer reference guide / Mono tank integrated type 173
9.3 Checklist before commissioning
Checklist before commissioning
Outdoor unit
Installation space is according manual (above average snow height/ enough clearances) Yes No
Outdoor unit is installed higher
/ same level / lower , than the indoor unit.
Product is protected against direct wind on fan/ snow ingress
Yes No
In case the product is installed close to sea, additional protection (coating) is applied
Yes No
Outdoor unit is correctly secured to base
Yes No
Provisions for condensate/ drainage are made, without any risk of freezing (tracing heating)
Yes No
All external pipework is insulated
Yes No
Power supply is installed with a dedicated correctly rated ELCB and correct cable sizing
Yes No
Voltage between (*optional: in case of 3PH) L1 - N
V~ L2 - N* V~ L3 - N* V~
Voltage between (*optional: in case of 3PH) L1 - N
V~ L2 - N* V~ L3 - N* V~
Voltage between N - PE
V~
Power supply is fitted with an isolator within in reach (arm length)
Yes No
ELCB fuse rating (Amps)
A
Mains power supply cable size (mm²)
mm²
Communication cable size (mm²)
mm²
Communication cable shielded, single sided connected to PE
Yes No
Additional refrigerant charge, split type (kg) (R32)
kg R
Total charge (kg) (R32)
kg R
Outdoor unit channel address setting (default is 00)
Outdoor unit noise restriction setting No (default) -3dB -5dB -7dB max.35dB
