9. Commissioning & Recommissioning
Installer reference guide / Mono tank integrated type 174
Indoor unit
Installation space is according manual (enough clearances) Yes No
Product is installed indoors without any risk of freezing, rain, moisture ingress
Yes No
Indoor unit is correctly secured to the floor (tank integrated)
Yes No
Provisions for condensate/ drainage are made (cooling/defrost), without any risk of flooding
Yes No
All external pipework is insulated
Yes No
Power supply is installed with a dedicated correctly rated ELCB and cable sizing for the indoor unit
Yes No
Indoor unit ELCB rating (Amps)
A
Mains power supply cable size (mm²)
mm²
Mains power supply cable length and size to indoor unit (m, mm²)
m mm²
Voltage between L1 - N
V~ L2 - N* V~ L3 - N* V~
Voltage between L1 - N2*
V~ L2 - L3* V~ L3 - L1* V~
Voltage between N - PE
V~
The power / amperage rating of the primary pump
W A
Default direction of 3way diverting valve
Room DHW
3-phase models only
9.4 Air purging
When commissioning and installing the unit, it is very important to remove all air in the water circuit.
Automatic air purging is possible via manually starting the primary pump of the ClimateHub via the self test mode (water
pump On/Off) in the service menu (password 0202) of the wired remote controller.
Before commissioning the unit, make sure to check the following points:
1 The maximum water pressure of the unit is 2.9 bar static pressure.
2
3 The minimum required water flow for operation is 16 liters/min (this is not the same as the standard or nominal flow, for
details see section 6.1 Flow Rate).
At all times the required water flow rates should remain.
A flow error can stop the compressor.
• Water quality must be according to EN directive 98/83 EC.
• If the unit and the pipes are exposed to freezing temperature, it can cause damage to the hydraulic system. Special
care must be taken to prevent freezing of the total water system.
• The unit is designed to be used in a closed-loop system. Do not use any other components which are designed only for
an open-loop system.
• Never use Zn-coated parts in the water circuit.
• All hydraulic parts including field piping must be insulated to reduce heat loss and condensation.
