7. Electrical installation
Installer reference guide / Mono tank integrated type 82
Terminal block specification
Units : mm
Phase Model AC Power Communication
1 Phase
AE050RXYDEG
AC power : M5 screw
10.1
13.1
N
L
Communication : M4 screw
N
L
11.4
10.1
AE080BXYDEG
AE120BXYDEG
AE140BXYDEG
AE080RXYDEG
AE120RXYDEG
AE160RXYDEG
AC power : M5 screw
17
13
N
L
NTSR
10.1
Communication : M4 screw
N
L
NTSR
3 Phase
AE080BXYDEG
AE120BXYDEG
AE140BXYDEG
17
12
AC power : M5 screw
N
L
NTSR
N
L
NTSR
10.1
Communication : M4 screw
AE080RXYDEG
AE120RXYDEG
AE160RXYDEG
N
L3(T)
L2(S)
L1(R)
2(N)1(L)
9.8 14.19
AC power : M5 screw
10.1
Communication : M4 screw
