Samsung HW-E6500 - Technical Specifications

English 39
06 Other Information
Specifications
GENERALZ
Weight 5.4 Kg
Dimensions (W x H x D) 429.2 x 165.1 x 360 mm
Operating temperature range +5°C~+35°C
Operating humidity range 10%~75%
FM TUNER
Frequency response 87.5~108.0MHz
Usable sensitivity 12dBf
S/N ratio MONO/STEREO 60dB/60dB
Distortion MONO/STEREO 0.3/0.8%
Stereo separation 30dB
Tuner output level 1kHz, 75kHz Dev
AMPLIFIER
Total max output THD=20%, 650mV, 1200W
Rated output 20Hz~20kHz/THD = 10%
Front speaker (left+right) 4 Ω 150W/CH
Center speaker 4 Ω 150W/CH
Surround speaker (left+right) 4 Ω 150W/CH
Double subwoofer 4 Ω 150W/CH
Input sensitivity/impedance 550mV/47kΩ
S/N ratio (analog input) 65dB
Separation (1kHz) 55dB
FREQUENCY
RESPONSE
Analog input 20Hz~20kHz(±3dB)
Digital input/96kHz PCM 20Hz ~44kHz(±3dB)
HDMI
Input Compatible 1080p
Output Compatible 1080p
VIDEO OUTPUT
TV format NTSC/PAL
Input level/impedance 1Vp-p/75 Ω
Output level/impedance 1Vp-p/75 Ω
Video frequency response 5Hz to 10kHz(-3dB)
S/N Ratio 60dB
* S/N Ratio, Distortion, Separation and Usable sensitivity are based on measurement using AES (Audio
Engineering Society) guidelines.
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
- Weight and dimensions are approximate.
- Design and specifications are subject to change without prior notice.
