ENGLISH-37
03 ADVANCED OPERATION
• Code 30 : User’s options for domestic hot water(DHW) tank heating
3011 : Application of DHW tank in user’s system
302 : Heat pump variables for tank temp. control and combination with booster heater
303 : Booster heater variables for combination with heat pump
304 : Periodical disinfection heating of water tank
305 : O timer for power DHW mode by Forced DHW of wired remote controller
3061 : Combination of external eld solar panel for with heat pump for DHW heating
307 : Default direction of the DHW valve or Zone #1, #2 valve
When the 3way valve is applied to DHW Valve terminal block instead of 2way valve, default direction is Space
Heating (Room)
Field Setting Value
Main Menu &
Code
Sub Menu Function Description Sub Code Default Min Max Step Unit
DHW Code
30
Domestic Hot Water Tank
Application 11 0(No) 0 1(Yes) - -
Heat Pump
Max Temp 21 50 45 50 1 ˚C
Stop 22 2 2 10 1 ˚C
Start 23 5 5 20 1 ˚C
Min. Space heating
operation time
24 5 1 20 1 min
Max. DHW operation time 25 30 5 95 5 min
Max. Space heating
operation time
26 3 0.5 10 0.5 hour
Booster Heater
Application 31 1(On) 0(O) 1 - -
Delay Time 32 20 20 95 5 min
Overshoot 33 0 0 4 1 ˚C
Compensation Temp 34 10 0 20 1 ˚C
Disinfection
Application 41 1(On) 0(O) 1 - -
Interval 42 Fri(5) Sun(0) All(7) 1 day
Start Time 43 23 0 23 1 o'clock
Target Temp 44 70 40 70 5 ˚C
Duration 45 10 5 60 5 min
Forced DHW operation
Timer OFF Function 51 0(O) 0 1(On) - -
Timer Duration 52 6 3 30 1
(x10)
min
Solar Panel/DHW Thermostat
H/P Combination 61 0 0 2 - -
Direction of DHW valve
DHW Tank 71 0(Room) 0 1(Tank) - -
