Field setting mode
Field Setting Value (FSV) Table
• Reset the power after changing the Field Setting Value.
NOTE
• Code 10 : Upper and lower temperature limits of each operation mode of wired remote controller Heating(Water Out,
Room), Cooling(Water Out, Room), DHW(Tank)
• Code 20 : Water law design and external room thermostat Heating(2 WL’s for oor & FCU), Cooling(2 WL’s for oor &
FCU), WL & Thermostat types
Field Setting Value
Main Menu &
Code
Sub Menu Function Description Sub Code Default Min Max Step Unit
Remote
Controller
Setting Range
Code 10
Water Out Temp for Cooling
Max 11 25 18 25 1 ˚C
Min 12 16 5 18 1 ˚C
Room Temp for Cooling
Max 21 30 28 30 1 ˚C
Min 22 18 18 28 1 ˚C
Water Out Temp for Heating
Max 31 55 37 55 1 ˚C
Min 32 25 15 37 1 ˚C
Room Temp for heating
Max 41 30 18 30 1 ˚C
Min 42 16 16 18 1 ˚C
DHW Tank Temp
Max 51 50 50 70 1 ˚C
Min 52 40 30 40 1 ˚C
Water Law
Code 20
Outdoor Temp for Water Law (Heating)
H1
11 -10 -20 5 1 ˚C
H2
12 15 10 20 1 ˚C
Water Out Temp for WL1 Heating
(WL1-Floor)
H1
21 40 17 55 1 ˚C
H2
22 25 17 55 1 ˚C
Water Out Temp for WL2 Heating (WL2-
Fan Coil Unit)
H1
31 50 17 55 1 ˚C
H2
32 35 17 55 1 ˚C
Heating Water Law for Auto Mode
WL Type 41 1(WL1) 1 2 - -
Outdoor Temp for Water Law (Cooling)
C1
51 30 25 35 1 ˚C
C2
52 40 35 45 1 ˚C
Water Out Temp for WL1 Cooling
(WL1-Floor)
C1
61 25 5 25 1 ˚C
C2
62 18 5 25 1 ˚C
Water Out Temp for WL2 Cooling (WL2-
Fan Coil Unit)
C1
71 18 5 25 1 ˚C
C2
72 5 5 25 1 ˚C
Cooling Water Law for Auto Mode
WL Type 81 1(WL1) 1 2 - -
External Thermostat Application
#1(Floor) 91 0(No) 0 1(Yes) - -
#2(FCU) 92 0(No) 0 1(Yes) - -
