ENGLISH-48
Field setting mode
Others : Code 50
Field Setting Value
Main Menu &
Code
Sub Menu Function Description Sub Code Default Min Max Step Unit
Others Code
50
Outing
Water Out Temp for Cooling 11 25 5 25 1 ˚C
Room Temp for Cooling 12 30 18 30 1 ˚C
Water Out Temp for Heating 13 15 15 55 1 ˚C
Room Temp for Heating 14 16 16 30 1 ˚C
Auto Cooling WL1 Temp 15 25 5 25 1 ˚C
Auto Cooling WL2 Temp 16 25 5 25 1 ˚C
Auto Heating WL1 Temp 17 15 15 55 1 ˚C
Auto Heating WL2 Temp 18 15 15 55 1 ˚C
Target Tank Temp 19 30 30 70 1 ˚C
DHW Saving Mode
Temp Dierence 21 5 0 40 1 ˚C
Power Peak Control
Application 41 0(No) 0 1(Yes) - -
Select forced o parts 42 0(All) 0 2 1 -
Using input voltage 43 1(High) 0(Low) 1 - -
Frequency Ratio Control
51 0(No) 0 1(Yes) - -
Outing Mode (Hot Key of Wired Remote Controller)
• All the target temperatures – space heating and cooling, water law, DHW, Room temperature – are set to the values
dened in the above table under the holiday mode (outing hot key)
• With the lowered target temperatures (FSV #5011 ~ #5019), the system operates normally.
NOTE
Economic DHW Heating
• DHW heating only by the heat pump to save energy. Target DHW temperature is lower than the temperature set by user.
The temperature dierence is dened by FSV #5021. (default: 5°C)
- If user sets the temperature 45°C, the system sets the target temperature 40°C with the default setting.
Peak Power Control
• If users make contracts with local electric power company for limiting the amount of power consumption when a surge in
power usage, users can set FSV of “Forced o”.
• According to FSV (#5041), Default is Non-usage. And According to FSV (#5042), If input is “0 (default)”, Back up heater (BUH)
is unavailable while external contact is high.
If input is “1”, Only Compressor (Heat Pump) is available.
If input is “2”, Only Booster Heater (BSH) is available.
• Applying the control when power voltage of input contact is high is default. According to FSV (#5043), it is available to
adopt this logic in low condition exceptionally.
• When applying to this logic, SAMSUNG controller come to get “Thermo o” condition for all operation.
• If not used for a long time, anti-freeze uid shall be used for preventing damage to the unit in cold condition.
OTHERS
