ENGLISH-43
03 ADVANCED OPERATION
Field Setting Value
Main Menu &
Code
Sub Menu Function Description
Sub
Code
Default Min Max Step Unit
DHW Code
30

Domestic Hot Water Tank
Application

11 0(No) 0 1(Yes) - -
Heat Pump
Max Temp

21 50 45 50 1 ˚C
Stop

22 2 2 10 1 ˚C
Start

23 5 5 20 1 ˚C
Min. Space heating operation
time

24 5 1 20 1 min
Max. DHW operation time

25 30 5 95 5 min
Max. Space heating operation
time

26 3 0.5 10 0.5 hour
Booster Heater
Application

31 1(On) 0(O) 1 - -
Delay Time

32 20 20 95 5 min
Overshoot

33 0 0 4 1 ˚C
Compensation Temp

34 10 0 20 1 ˚C
Disinfection
Application

41 1(On) 0(o) 1 - -
Interval

42 Fri(5) Sun(0) All(7) 1 day
Start Time

43 23 0 23 1 o'clock
Target Temp

44 70 40 70 5 ˚C
Duration

45 10 5 60 5 min
Forced DHW operation
Timer OFF Function

51 0(O) 0 1(On) - -
Timer Duration

52 6 3 30 1
(x10)
min
Solar Panel/DHW Thermostat
H/P Combination

61 0 0 2 - -
Direction of DHW valve
DHW Tank

71 0(Room) 0 1(Tank) - -
DHW Application
The FSV #3011 in the wired remote controller should be set to “1(Yes)” to use DHW function.
Heat Pump Variables for Controlling DHW Tank
• Maximum DHW tank temperature with R-410A(refrigerant) heat pump operation : FSV #3021, Default 50˚C,
Range : 45 ~ 50˚C.
• Temperature dierence determining the heat pump OFF temperature : FSV #3022, Default 2˚C, Range : 2 ~ 10˚C.
• Temperature dierence determining the heat pump ON temperature : FSV #3023, Default 5˚C, Range : 5 ~ 20˚C.
• DHW heating mode timer : Mode timer manage the operation terms when there are simultaneous requests of space
heating/cooling and DHW.
- FSV #3024(minimum Space heating operating time, Default 5 min., Range 1 ~ 20 min.), #3025(maximum DHW time,
Default 30 min., Range 5 ~ 95 min.), #3026(maximum space heating operation time, Default 3 hour, Range 0.5 ~
10hour)
- Maximum operation time is applied only when both DHW and Space heating request operation. DHW or Space heating
operates continuously until reaching at target temperature without time limitation in the single operation.
• The FSV #4011 for DHW priority should be set to “0(DHW)”(Default). Space heating gets a priority by setting FSV
#4011 “1”, but this is only valid when the outdoor temperature is lower than the specied temperature dened
by FSV #4012.
NOTE
