Field setting mode
English
Field Setting Mode
Classification Function Detail
Code
(Main
+ sub
menu)
Basic Min. Max. Step Unit
Others
Outing mode
Indoor heating
temperature
5014 16 16 30 1 °C
Temperature of auto
heating WL1 water
5017 25 25 ߩߡ 1°C
Temperature of auto
heating WL2 water
ߦߡߢߩ 25 25 ߩߡ 1°C
Temperature of hot
water Tank
5019 35 35 75 1 °C
Economic DHW mode
Temperature of hot
water Tank
5021 5 0 40 1 °C
Smart grid (Power peak
control)
Operation 5041 0 (No) 0 1 (Yes) - -
Heat source for
operation limit
5042 0 (All) 0 2 1 -
Contact Logic 5043
1
(High)
0
(Low)
1--
Ratio of hot water supply
compare to heating
A/7 (Ratio is
determined based
on the value of the
A)7 means Heating
capacity=Hot water
capacity
5061 7 1 7 1 -
Functions that requires setting according to field specification
࡙ Code: 10**
ࣕ Upper and lower temperature limits for Heating (Water out, Room), Cooling (Water out, room), DHW
(Tank) mode
ࣕ 1011: Maximum Value of cooling leaving water temperature setting in wired remote controller
ࣕ 1012: Minimum Value of cooling leaving water temperature setting in wired remote controller
ࣕ 1021: Maximum Value of cooling indoor’s room temperature setting in wired remote controller
ࣕ 1022: Minimum Value of cooling indoor’s room temperature setting in wired remote controller
ࣕ 1031: Maximum Value of heating leaving water temperature setting in wired remote controller
ࣕ 1032: Minimum Value of heating leaving water temperature setting in wired remote controller
ࣕ 1041: Maximum Value of heating indoor’s room temperature setting in wired remote controller
ࣕ 1042: Minimum Value of heating indoor’s room temperature setting in wired remote controller
ࣕ 1051: Maximum Value of hot water tank temperature setting in wired remote controller
ࣕ 1052: Minimum Value of hot water tank temperature setting in wired remote controller
