Field Setting Mode
Smart Grid Control
NOTE
࡙ MIM-E03CN(MONO Control Kit) model does not support this Smart grid function.
The FSV #5091 should be set to "1(Yes)" for Smart Grid control.
FSV 0 1
#5091 Disable (Default) Activation
Operation mode for Smart Grid
Operation Mode Terminal 1 Terminal 2
Mode 1 Short Open
Mode 2 Open Open
Mode 3 Open Short
Mode 4 Short Short
࡙ Mode 1 : Forced thermo off operation of all system
࡙ Mode 2 : Normal operation
It is equally applied both heating and hot water mode.
࡙ đͱʒʪߤࡠĘͱθɇͱΧʪθɇϩͱ࣍ƊǤࢄߦߡߪߣߣঐࡡƊǤࢄߦߡߪߤߦঐࡡUʪ˙ɇЇϩ࣎
The heating and hot water setting temperature are set by the FSV setting value.
ࣕ Heating mode (Room sensor setting) : Current setting value + FSV #5092
ࣕ Heating mode (Water outlet setting) : Current setting value + FSV #5092
ࣕ Heating mode (Water law setting) : Current setting value + FSV #5092
ࣕ Hot water mode : Current setting value + FSV #5093
࡙ Mode 4 : When operating on, the setting temperature is reflected as follows.
Hot water mode
ࣕ ࢄߦߡߪߥߡࡠƟɇθ˝ʪϩϑʪϩϩ˝ϩʪΧʪθɇϩЇθʪϑߦߦঐࢋ
ࣕ ࢄߦߡߪߥߢࡠƟɇθ˝ʪϩϑʪϩϩ˝ϩʪΧʪθɇϩЇθʪϑߨߡঐࢋ
[If FSV #3031 is 0 (no use booster heater) or DHW mode is economic mode, it does not
activate booster heater.]
Heating mode
ࣕ ²ʪɇϩ˝ͱʒʪ࣍ŵͱͱϑʪϑͱθϑʪϩϩ˝࣎ࡠAЇθθʪϩϑʪϩϩ˝ЭɇЇʪƊǤࢄߦߡߪߣߤঐ࣍đɇуƊǤࢄߢߡߥߢ࣎
ࣕ ²ʪɇϩ˝ͱʒʪ࣍ǮɇϩʪθͱЇϩʪϩϑʪϩϩ˝࣎ࡠAЇθθʪϩϑʪϩϩ˝ЭɇЇʪƊǤࢄߦߡߪߣߦঐ࣍đɇуƊǤࢄߢߡߤߢ࣎
ࣕ ²ʪɇϩ˝ͱʒʪ࣍Ǯɇϩʪθɇиϑʪϩϩ˝࣎ࡠAЇθθʪϩϑʪϩϩ˝ЭɇЇʪƊǤࢄߦߡߪߣߦঐ
(Max=FSV #2021, #2022, #2031, #2032)
