Field Setting Mode
Field Setting Value (FSV) 20**
Code 20** : Water law design and external room thermostat Heating(2 WL’s for floor & FCU),
Cooling(2 WL’s for floor & FCU), WL & Thermostat types
• The values in the following table are just examples for your understanding.
Main Code Menu
Function
Sub
Code
Remark
F.S.
Value
MODEL CODE : AE***DN*MPK /
AE***DN*SPG / MIM-E03FN
MODEL CODE :
AE***DN*THP
Setting Standard Setting Standard
Item Step Unit Default
Min.
value
Max. value
Default
Min.
value
Max. value
Water
Law Code
20**
Heating
Outdoor
Temperature for
Heating Water Law
Max 1  2011 -10 -20 5 -10 -20 5
Min 1  2012 15 10 20 15 10 20
Water out
Temperature for
WL1 Heating (UFHs)
Max 1  2021 40 17 65/70/75
(*1)
40 17 55
Min 1  2022 25 17 65/70/75
(*1)
25 17 55
Water out
Temperature for
WL2 Heating
(FCUs)
Max 1  2031 50 17 65/70/75
(*1)
50 17 55
Min 1  2032 35 17 65/70/75
(*1)
35 17 55
Heating Water Law
Selection
WL Type - - 2041 1 (WL1) 1 2 1 (WL1) 1 2
Cooling
Outdoor
Temperature for
Cooling Water Law
Max 1  2051 30 25 35 30 25 35
Min 1  2052 40 35 45 40 35 45
Water out
Temperature for
WL1 Cooling (UFHs)
Max 1  2061 25 5 25 25 5 25
Min 1  2062 18 5 25 18 5 25
Water out
Temperature for
WL2 Coolingg
(FCUs)
Max 1  2071 18 5 25 18 5 25
Min 1  2072 5 5 25 5 5 25
Cooling Water Law
Selection
WL Type - - 2081 1 (WL1) 1 2 1 (WL1) 1 2
External
Control
External Room
Thermostat
#1 (UFHs) 1 - 2091 0 (No) 0 4 0 (No) 0 4
#2 (FCUs) 1 - 2092 0 (No) 0 4 0 (No) 0 4
Remote
Controller
Remote Controller Room Temp.
Control
1 - 2093 4 1 4 4 1 4
NOTE
•
(*1)
The value is determined according to the type of outdoor unit.
