Field setting mode
30
English
Field Setting Mode
Field Setting Value (FSV) 30**
Code 30** : User’s options for Domestic Hot Water(DHW) tank heating
• The values in the following table are just examples for your understanding.
Main Code Menu
Function
Sub
Code
MODEL CODE : AE***DN*MPK /
AE***DN*SPG / MIM-E03FN
MODEL CODE :
AE***DN*THP
Setting Standard Setting Standard
Item Step Unit Default
Min.
value
Max. value
Default
Min.
value
Max.
value
Domestic
Hot Water
Tank Code
30**
DHW
DHW mode
activate
DHW mode - - 3011
1
(*3)
0
(*3)
2
(*3)
1
(*3)
0
(*3)
2
(*3)
0
(*4)
0
(*4)
2
(*4)
0
(*4)
0
(*4)
2
(*4)
Heat Pump
Max. Temp. 1  3021 55/63/70
(*1)
45 55/63/70
(*1)
53 45 53
Stop 1  3022
0
(*3)
0
(*3)
10
(*3)
0
(*3)
0
(*3)
10
(*3)
2
(*4)
0
(*4)
10
(*4)
2
(*4)
0
(*4)
10
(*4)
Start 1  3023 5 5 30 5 5 30
Min. Operating
Time
1 min 3024 5 1 20 5 1 20
Max. Operating
Time
5 min 3025 30 5 95 30 5 95
Operation Interval 30 min 3026 180 30 600 180 30 600
Booster Heater
On/Off - - 3031 1 (On) 0 (Off) 1 1 (On) 0 (Off) 1
Delay Time 5 min 3032 20 20 95 20 20 95
Overshoot 1  3033 0 0 4 0 0 4
Disinfection
On/Off - - 3041 1 (On) 0 (Off) 1 1 (On) 0 (Off) 1
Interval 1 day 3042 Fri (5) Sun (0) All (7) Fri (5) Sun (0) All (7)
Start Time 1 o'clock 3043 14/23
(*1)
0 23 23 0 23
Target Temp. 5  3044 70 40 70 70 40 70
Duration 5 min 3045 10 5 60 10 5 60
Max time 1 hour 3046 8 1 24 8 1 24
Power DHW by
User Input
Timer OFF Function - - 3051 0 (No) 0 1 (Yes) 0 (No) 0 1 (Yes)
Time Duration 1 (x10)min 3052 6 3 30 6 3 30
Solar Panel/DHW
Thermostat
H/P Combination 1 - 3061 0 (No) 0 2 0 (No) 0 2
3-way Valve Defalut Direction - - 3071 0 (Room) 0 1 (Tank) 0 (Room) 0 1 (Tank)
Addition
Function
Energy metering
Backup Heater
capacity
1 kW 3081 2 1 6 2 1 6
Booster Heater
capacity
1 kW 3083 3 1 6 3 1 6
