Field setting mode
42
English
Field Setting Mode
Field Setting Value (FSV) 50**/60**
Code 50**/60** : User’s options for extra functions
• The values in the following table are just examples for your understanding.
Main Code Menu
Function
Sub
Code
MODEL CODE : AE***DN*MPK /
AE***DN*SPG / MIM-E03FN
MODEL CODE : AE***DN*THP
Setting Standard Setting Standard
Item Step Unit Default Min. value Max. value Default Min. value Max. value
Others
Code 50**
Away Mode
Water Out Temperature
for Cooling
1  5011 25 5 25 25 5 25
Room Temperature for
Cooling
1  5012 30 18 30 30 18 30
Water Out Temperature
for Heating
1  5013 15 15 55 15 15 55
Room Temperature for
Heating
1  5014 16 16 30 16 16 30
Cooling WL1 Temp. 1  5015 25 5 25 25 5 25
Cooling WL2 Temp. 1  5016 25 5 25 25 5 25
Heating WL1 Temp. 1  5017 15 15 55 15 15 55
Heating WL2 Temp. 1  5018 15 15 55 15 15 55
DHW tank Temp. 1  5019 30 30 70 30 30 70
DHW Saving
DHW Saving Temp 1  5021 5 0 40 5 0 40
DHW Saving Mode 1 - 5022 0 0 1 0 0 1
DHW Saving Thermo
on Temp.
1  5023 25 0 40 25 0 40
TDM variables
A2W Max. Operation
Time
5 min 5031 N/A N/A N/A 30 10 90
A2W Min. Operation
Time
1 min 5032 N/A N/A N/A 5 5 60
A2W / DHW Priority 1 - 5033 N/A N/A N/A 0 (A2A) 0 1 (DHW)
Power Peak Control
Application - - 5041 0 (No) 0 1 (Yes) 0 (No) 0 1 (Yes)
Select forced off parts 1 - 5042 0 (All) 0 3 0 (All) 0 3
Using input voltage - - 5043 1 (High) 0 (Low) 1 1 (High) 0 (Low) 1
Frequency Ratio Control - - 5051 0 (No) 0 1 (Yes) 0 (No) 0 1 (Yes)
Addition
Function
PV control
Application 1 - 5081 0 (No) 0 1 (Yes) 0 (No) 0 1 (Yes)
Setting Temp Shift
Value(Cooling)
1  5082 2 1 20 2 1 20
Setting Temp Shift
Value(Heating)
1  5083 2 1 50 2 1 50
