Samsung OfficeServ500 - MDF Connections RJ-45 to 8 BSI Card

CONNECT TO ANY PORT ON
ANY 8BSI CARD
(NB: POLARITY IS IMPORTANT)
RJ-45 Connector
Pin No
Port Signal
4 1
5
D cha nnel data
26
6 27
3
0
Sync line
2
4 4
5
D cha nnel data
29
6 30
3
1
Sync line
5
4 7
5
D cha nnel data
32
6 33
3
2
Sync line
8
4 10
5
D cha nnel data
35
6 36
3
3
Sync line
11
4 13
5
D cha nnel data
38
6 39
3
4
Sync line
14
4 16
5
D cha nnel data
41
6 42
3
5
Sync line
17
4 19
5
D cha nnel data
44
6 45
3
6
Sync line
20
4 22
5
D cha nnel data
47
6 48
3
7
Sync line
23
25 PAIR CABLE WITH FEMALE CONNECTOR TO 8BSI CARD
RJ-45 CONNECTOR
FIGURE 4-18 MDF CONNECTIONS RJ-45 TO 8BSI CARD
RST
ON
OFF
Champ
Pin No
Colour
B-W
W-B
W-O
O-W
Bn-W
W-Bn
W-S
S-W
O-R
R-O
R-Gn
Gn-R
S-R
R-S
Bk-B
B-Bk
Gn-Bk
Bk-Gn
Bk-Bn
Bn-Bk
B-Y
Y-B
Y-O
O-Y
Bn-Y
Y-Bn
Y-S
S-Y
O-Pu
Pu-O
Pu-Gn
Gn-Pu
CABLE 2pr twisted
THICKNESS 0.6mm or 0.4mm
MAX LENGTH 600m with 0.6mm / 400m with 0.4mm
INTERFACE 2 x U interface & 64 kbit/sec via 4 B-channels
