DISK DRIVE
VOICE
PROCESSING
MODULE
PORTS 5 - 8
VOICE
PROCESSING
MODULE
PORTS 1 - 4
POWER
REGULATOR
BACKPLANE
CONNECTOR
HDD ACCESS
RUN INDICATOR
SERIAL PORT
RESET BUTTON
V
M
8
A
xxxxxxxxx
PARALLEL PORT
FIGURE 4-20 SVMi-8 / CADENCE CARD
