ENGLISH
94
Specifications
Model name: SCD73/D75/D77
System
Video signal NTSC standards
Video recording system 2 rotary heads, Helical scanning system
Audio recording system Rotary heads, PCM system
Usable cassette Digital video tape (6.35mm width): Mini DV cassette
Tape speed SP: approx. 18.81mm/s LP: approx. 12.56mm/s
Tape recording time SP: 60 minutes (when using DVM 60)
LP: 90 minutes (when using DVM 60)
FF/REW time Approx. 150 sec. (using DVM60 tape)
Image device CCD (Charge Coupled Device)
Lens F1.6 22x(Optical), 500x(Digital) Electronic zoom lens
Filter diameter Ø37
LCD monitor/Viewfinder
Size/dot number 2.5inch/112,320
LCD monitor Method TFT LCD
Viewfinder 0.24” B/W LCD
Connectors
Video output 1Vp-p (75Ω terminated)
S-video output Y: 1Vp-p, 75Ω, C: 0. 286Vp-p, 75Ω
Audio output -7.5dBs (600Ω terminated)
DV input/output 4pin special in/out connector
USB output Mini-B type connector
External mic Ø3.5 stereo, -57 dBV (with 600 ohm mic)/at least 5 Kohms
