● OVERVIEW
Part Names Functions
eSATA Ports used for external storage device connections.
LOOP OUT Terminal used to send the video signal to another device.
ALARM
- ALARM IN : Alarm Input port.
SRD-876D : 1~8 CH
SRD-
1656D/1676D : 1~16 CH
- ALARM RESET : Alarm Reset port.
- ALARM OUT 1~4 : Alarm Output port.
RS-485 Used to establish RS485 communications. (TX+, TX-, RX+, RX-)
m
SERIAL Serial port for connecting to a POS device.
M
[CONSOLE] is designed for the service repair purpose only.
