Alarm setting
1. In the <Network> setting window, press the top down
(▲▼) button to move to the <Connection Mode> mode
and press the [ENTER] button.
2. Select the <Alarm> menu.
3. Press the top/down/left/right(▲▼◄►) button to toggle
settings and set up your preferences.
• Disconnect Alarm Output Port : Select a method for
outputting an alarm when network connection is terminated.
- If you select <1>, <2>, <3> or <4> the signal is outputted
from the alarm output terminal in the rear.
- If you select <BEEP>, the alarm sound will be played.
- If you select <ALL>, the alarms sounds and the warning sounds from the rear will be heard at the same
time.
• Duration : Select the duration of alarm signal outputs and warning sounds.
- It is outputted to the alarm output terminal (1, 2, 3, 4) selected in the connection cancellation alarm output
port.
- If you select <BEEP>, the alarm sound will be played.
- If you select <ALL>, the alarms sounds and the warning sounds from the rear will be set at the same
time.
4. After finishing setting the alarms, select <OK>.
Connection Mode
Interface
Port
Alarm
Disconnect Alarm Output Port
Duration OFF
OK Cancel
1 2 3
4 BEEP All
