• Function
Personal Computer converts Video Wall Mode of TV or Monitor when Video Wall is ON.
Only works with TV or Monitor where Video Wall is on.
Does not operate in MagicInfo
•
Get Video Wall Mode
Header command
ID
DATA Length
CheckSum
0xAA 0x5C 0
• Set Video Wall Mode
Header
command
ID
DATA
Length
DATA
CheckSum
0xAA 0x5C 1 Video Wall
Mode
Video Wall Mode : Video Wall Mode code to be set on TV or Monitor
1 : Full
0 : Natural
•
Ack
Header
com-
mand
ID
DATA
Length
Ack/Nak r-CMD Val1
Check
Sum
0xAA 0xFF 3 ‘A’ 0x5C
Video
Wall
Mode
Video Wall Mode : same as above
•
Nak
Header
com-
mand
ID
DATA
Length
Ack/Nak r-CMD Val1
Check
Sum
0xAA 0xFF 3 ‘N’ 0x5C ERR
ERR : Error code that shows what occurred error is
• Safety Lock
• Function
Personal Computer turns Safety Lock function of TV or Monitor ON / OFF.
Can operate regardless of whether power is ON / OFF.
