Samsung WALL MOUNTED TYPE - Indoor Unit Dimensions

13
Outline & Dimensions
Indoor Unit
1
AC
B
Air
in
(Front view)
(Remote control)
Type A B C
7K/ 9K/ 12K 190 246 165
18K/ 24K 1080 275 204
(Rear view)
7K/ 9K/ 12K
Air out
Installation plate
2245
115
18K/ 24K
