Features & Operation
62
Operation Characteristics
4
When selecting the Cooling Mode
Operation, the unit will operate according
to the setting by the remote controller and
the operation is as well as the following.
Room temperature can be set in 1°C
steps in the range of 18 to 30°C.
Cooling Mode Operation
1
♦ Ts means Remote Controller setting Temperature
Room Temp.(°C)
Ts+1
Ts
Compressor
On
Off
On
Time
When selecting the Heating Mode
Operation, the unit will operate according
to the setting by the remote controller and
the operation is as well as the following.
Room temperature can be set in 1°C
steps in the range of 16 to 30°C.
Heating Mode Operation
2
When Automatic operation is set by the remote controller, the air conditioner senses the room
temperature then automatically selects the operation mode and setting temperature.
Automatic Operation
3
Room Temp.(°C)
Ts+5
Ts+3
Compressor
On
Off
On
Time
Operating Mode Setting Temp. Remarks
Room Temp ≥ 21°C + ∆T Cooling Tsp = 24°C + ∆T
∆T = -2, -1, 0, 1, 2
Room Temp < 21°C + ∆T Heating Tsp = 22°C + ∆T
◆ In case that Room Temp. ≥ 21°C + ∆T, The Unit is operated in the Cool Mode.
◆ In case that Room Temp. < 21°C + ∆T, The Unit is operated in the Heat Mode.
◆ ∆T means that user is able to change setting temperature within ±2°C.
4-1 NON INVERTER
