Installation
38
1. Make sure that you install the outdoor unit in area not exposed to the rain or direct
sun light.(Install a separate sunblind if exposed to direct sun light.)
2. Make sure that you install the outdoor unit in area allowing the good air moment, not
amplifying noise or vibration, especially to avoid disturbing neighbours.
(Fix the unit firmly if it is mounted in a high place.)
3. Make sure that you install the outdoor unit in area providing the good ventilation and
which is not dusty. It must not be blocked by any obstacle affecting the airflow near
the air inlet and the air outlet.
4. Make sure that you install the outdoor unit in area free from animals or plants.
5. Make sure that you install the outdoor unit in area not blocking the traffic.
6. Make sure that you install the outdoor unit in area easy to drain condensed water
from the indoor unit.
7. Make sure that you install the outdoor unit in area which provides easy connection
within the maximum allowable length of a coolant pipe.
8. Make sure that you install the outdoor unit in an area which is large enough to
accommodate the measurements shown in figure on the next page.
Outdoor Unit
2
1. Make sure that you install the remote control unit in an area free from obstacles such
as curtains etc, which may block signals from the remote control unit.
2. Make sure that you install the remote control unit in an area not exposed to
direct sunlight, and where there is no source of heat.
3. Make sure that you install the remote control unit in an area away from TVs, audio
units, cordless phones, fluorescent lighting fixtures and other electrical appliances
(at least 1 meter).
Remote Control Unit
3
MODEL
7K
9K
12K
18K
24K
20(g/m)
20(g/m)
30(g/m)
30(g/m)
40(g/m)
The guantaty of Supplementary refrigerant
