Installation and Operation Manual
64
5-4 GPS antenna
5-4-1 antenna
Installing a antenna
install the antenna and fit the antenna cable
back to the display unit. Follow the
instructions in the manual supplied with the
antenna. Fit an optional extension cable if
required.
During setup, configure the data for the
chosen antenna.
5-4-2 The antenna using NMEA
The chart plotter can receive the GPS data
from the compatible device (NMEA). The
chart plotter can connect several devices to
an external GPS.
• An optional differential beacon DGPS
antenna to give enhanced accuracy within
range of land based differential beacons in
areas where WAAS or EGNOS are not
available. Such a DGPS antenna has both a
GPS receiver and a beacon receiver, and it
automatically applies the beacon correction
to the GPS position.
To set the DGPS options(None or
WAAS/EGNOS):
Connect the GPS directly to the input. Set the
option. The new setting will be displayed if it
was successfully applied.
Note:
The chart plotter can apply the WAAS and
EGNOS DGPS corrections to any GPS
antenna.
For more information, contact Samyung ENC.
