CW-6300 Series
8
2. Detailed parameter setting is as below table
Orde
r
Code
Set item
Range
Factory
setting
Remark
Register
address
1
F1
Set temp.
F6～F5/
-20～40
25
Intelligent mode /
Constant temp mode
0x0401
2
F2
Temp. difference values
-15～5
-2
0x0402
3
F3
Cooling hysteresis
0.1～3.0
0.8
0.1 resolution ratio
0x0403
4
F4
Way of control
0～1
0
0 Constant,
1 Intelligent
0x0404
5
F5
The highest set temp.
（F6+1）～40
35
Constant temp. mode
0x0405
6
F6
The lowest set temp.
1～（F5-1）
20
Min. 1, Constant
temp. mode invalid
0x0406
7
F7
Ultra-high room temp.alarm
40～50
45
0x0407
8
F8
Ultra-high water temp. alarm
1～20
10
0x0408
9
F9
Ultra-low water temp. alarm
1～20
15
0x0409
10
F10
Temp. alarm delay
0～30
5
Minute
0x040a
11
F11
Sensor failure alarm delay
0～180
10
Second
0x040b
12
F12
Water flow detection delay
of machine startup
0～180
5
Second
0x040c
13
F13
Flow alarm delay
0～180
2
Second
0x040d
14
F14
Heating hysteresis
0～10
0.8
0.1 resolution ratio
0x040e
15
F15
Water pump stop delay
0～180
5
Second
0x040f
16
F16
Startup delay
0～180
30
Second
0x0410
17
F17
Compressor activate
protection
0～180
90
Second
0x0411
18
F18
Turn on setting of phase
sequence protection
On off
/
Single-phase OFF /
three-phase ON
0x0412
19
F19
Turn on setting of external
input function (startup and
standby)
On off
off
0x0413
20
F20
NO and NC setting of external
input function
NO/NC
NC
NO-normally opened
NC-normally closed
0x0414
21
F21
External input activation delay
0～180
0
Second
0x0415
22
F22
External input standby
activation delay
0～180
0
Second
0x0416
23
F23
Key lock of Chiller On/Off
0-1
1
0：lock
1：unlock
0x0436
24
F24
Self-starting after being
electrified
On off
off
0x043d
