CWUL-05/10/20 Series
4
<2> Outlook and Components
WATER INJECTION PORT
COOLING WATER OUTLET
COOLING WATER INLET
AIR OUTLET
DRAIN
WATER LEVEL GAUGE
POWER SOCKET(WITH FUSE)
(WITH FUSE)
POWER SWITCH
TEMPERATURE
CONTROLLER
AIRINLET
(FILTER GAUZE)
