S&C Instruction Sheet 716-502 25
Figure 23. Check the motor contactor and surge suppressor
behind the operator side panel.
Surge suppressor out of place. Push the surge support
(if present) back into place.
Motor contactors should be fully seated
(if present) back into place.
Motor contactors should be fully seated
Figure 24. Check that all optional “ice cube” style relays are
fully seated and that the retaining plate is in place.
Optional
relays
Retaining
plate
Installation
To Next Page
