S&C IntelliCap 2000 User Manual

Figure 14. Enclosure dimensions with pole-mount bracket.
11.35 (288)
5.00(127)
.75 (19)
.56 (14)
10.25 (260)
20.00 (508)
13.00 (330)
1.50 (38)
14.79 (376)
18.00 (457)
.84 (21)
2.50
(64)
9.85
(250)
.56 (14)
1.13 (29)
IntelliCap
®
2000
Automatic Capacitor
Control
Installing the Capacitor Control
Dimensions in inches (mm)
16 S&C Instruction Sheet 1024-510
