Model SA2-A Page 8 520-010-000 5/03
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most Warren
Rupp distributors. The pump owner may
prefer to maintain a limited inventory of these
parts in his own stock to reduce repair
downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
000... Assembly, sub-assembly; and some
purchased items
010... Cast Iron
015... Ductile Iron
025... Music Wire
080... Carbon Steel, AISI B-1112
110... Alloy Type 316 Stainless Steel
112... Alloy “C”
114... 303 Stainless Steel
115... 301/302/304 Stainless Steel
120... 416 Stainless Steel (Wrought Martensitic)
148... Hardcoat Anodized Aluminum
150... 6061-T6 Aluminum
151... 6063-T6 Aluminum
154... Almag 35 Aluminum
155 or 156...356-T6 Aluminum
157... Die Cast Aluminum Alloy #380
159... Anodized Aluminum
162... Brass, Yellow, Screw Machine Stock
170... Bronze, Bearing Type, Oil Impregnated
180... Copper Alloy
330... Plated Steel
331... Chrome Plated Steel
332... Electroless Nickel Plated
335... Galvanized Steel
354... Injection Molded #203-40 Santoprene —
Duro 40D +/-5; Color: RED
356... Hytrel
357... Rupplon (Urethane Rubber)
360... Buna-N Rubber. Color coded: RED
363... Viton (Fluorel). Color coded: YELLOW
364... E.P.D.M. Rubber. Color coded: BLUE
365... Neoprene Rubber. Color coded: GREEN
366... Food Grade Nitrile. Color coded: WHITE
375... Fluorinated Nitrile
405... Cellulose Fibre
408... Cork and Neoprene
425... Compressed Fibre
440... Vegetable Fibre
500... Delrin 500
501... Delrin 570
520... Injection Molded PVDF, Natural Color,
Food Grade/USDA Acceptable
540... Nylon
550... Polyethylene
551... Polypropylene
555... PVC (Polyvinyl Chloride)
580... Ryton
600... PTFE (virgin material) Tetrafluoroethylene (TFE)
603... Blue Gylon
604... PTFE — Diaphragm
610... Encapsulated Silicon
611... PTFE Encapsulated Viton
Delrin, PTFE, Hytrel, and Viton are
registered tradenames of E.I. DuPont.
Gylon is a registered tradename of Garlock, Inc.
Warren Rupp, Rupplon and SandPIPER are registered
tradenames of Warren Rupp, Inc.
Ryton is a registered tradename of Phillips
Chemical Company.
Loctite is a registered tradename of Loctite Corporation.
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
171-002-110 Capscrew, Socket Head 2
31 545-007-330 Nut, Hex 16
(AL Units use 8)
32 807-008-330 Stud 16
33 900-006-330 Washer, Lock 8
(AL Units use 12)
34 612-047-330 Plate, Diaphragm 2
35 312-012-156 Elbow, Suction 2
312-012-110 Elbow, Suction 2
312-012-010 Elbow, Suction 2
334-014-156 Flange, Suction (Dual Ported Only) 2
334-014-010 Flange, Suction (Dual Ported Only) 2
36 312-013-156 Elbow, Discharge 2
312-013-110 Elbow, Discharge 2
312-013-010 Elbow, Discharge 2
334-015-010 Flange, Discharge (Dual Ported Only) 2
334-015-156 Flange, Discharge (Dual Ported Only) 2
37 338-010-357 Flap Valve 4
338-005-365 Flap Valve 4
338-005-360 Flap Valve 4
338-005-366 Flap Valve 4
338-005-363 Flap Valve 4
338-005-364 Flap Valve 4
338-010-356 Flap Valve 4
338-010-354 Flap Valve 4
38 360-011-425 Gasket, Seat 4
360-011-366 Gasket, Seat 4
39 360-012-379 Gasket, Flange 4
360-012-384 Gasket, Flange 4
360-012-366 Gasket, Flange 4
722-070-363 Seat, Flap Valve (Viton only) 4
722-070-364 Seat, Flap Valve (EPDM & Santoprene only) 4
40 518-001-157 Manifold, Discharge, Suction 2
518-001-010 Manifold, Discharge, Suction 2
518-001-110 Manifold, Discharge, Suction 2
42 570-001-365 Pad, Hinge — Flap Valve 4
570-001-366 Pad, Hinge — Flap Valve 4
570-001-360 Pad, Hinge — Flap Valve 4
570-001-363 Pad, Hinge — Flap Valve 4
570-001-364 Pad, Hinge — Flap Valve 4
43 670-005-110 Retainer, Flap Valve 4
44 675-013-365 Ring, Sealing 4
675-013-360 Ring, Sealing 4
675-013-363 Ring, Sealing 4
675-013-366 Ring, Sealing 4
675-013-364 Ring, Sealing 4
45 722-004-110 Seat, Flap Valve 4
722-070-364* Seat, Flap Valve 4
722-070-360* Seat, Flap Valve 4
722-070-363* Seat, Flap Valve 4
46 770-005-330 Spacer 2
47 807-018-110 Stud 8
48 170-052-330 Capscrew, Hex Head 2
49 170-026-330 Capscrew, Hex Head 2
50 545-005-330 Nut, Hex 20
51 900-005-330 Washer, Lock 24
52 547-002-110 Nut, Stop 8
53 902-003-000 Stat-O-Seal 2
54 530-036-000 Muffler, Exhaust 1
55 560-046-360 O-Ring 2
560-070-610 O-Ring 2
57 612-007-150 Plate, Base 1
612-007-080 Plate, Base 1
59 170-018-330 Capscrew, Hex Head 4
62 031-019-156 Main Air Valve Assembly 1
031-019-010 (Inc. Items 9, 10, 11, 13, 14, 15, 16)
64 132-022-360 Bumper 2
65 170-035-330 Capscrew, Hex Head (AL Units only) 8
