Sansui VHF6010 - Basic Connections - Antenna Input Configurations

15
ENGLISH
OUT
IN
VCR
VCR
VCR
This VCR has a single 75 ohm antenna input for connection to an antenna (VHF/UHF) or cable (CATV) system.
If you have separate VHF and UHF antennas (number 3 below), use a combiner to connect the antennas to
the VCR.
NOTE: If a VHF or UHF antenna is
used, set the TV/CATV
menu option to the "TV"
mode.
NOTE: If a VHF or UHF antenna is
used, set the TV/CATV
menu option to the "TV"
mode.
NOTE: If a VHF or UHF antenna is
used, set the TV/CATV
menu option to the "TV"
mode.
Combiner
75/300 ohm Inputs
75 ohm output
(not supplied)
Matching Transformer
300 ohm Input
75 ohm output
(not supplied)
OUT
IN
OUT
IN
