Sanus BLT3 - TV Operation and Removal; Extend and Retract Mount; Swivel Functionality; Lock TV to Wall Plate

11
1. Disconnect all cables.
2. To unlock the TV from the wall plate: Lift
the release latch
R
on both brackets.
3. Lift the TV up and off of wall plate
07
.
NOTE: To rehang the TV, follow the
procedures in STEP 3 on PAGE 9.
1
EXTEND
RETRACT
1
2
CAUTION: Avoid potential
personal injury or property damage!
The TV brackets contain potential
pinch points during operation.
Keep fingers away from pinch points
when retracting the TV. (see arrows)
REMOVING THE TV
3
HEAVY! You may need
assistance with this step.
2
R
05
04
07
05
04
SWIVEL
05 04
05 04
LOCK
