Sanwa PC5000a - Start-Up Inspection

D-1034-143 PC5000a（E）
DRAWING No. PC5000a 07-0812 2040 6010
The buzzer sounds?
Check continuty of test
leads
Main unit
and test leads
damaged?
Set the function to " ".
[5] MEASUREMENT PROCEDURE
5-1 Start-Up Inspection
START
Short the red and black
test pins.
No damaged
No problem.
Start measurement.
Yes
Stop using it and have
it repaired.
—
11
—
1. Never use meter if the meter or test leads are damaged or
broken.
2. Make sure that the test leads are not cut or otherwise damaged.
WARNING
Damaged
