[2] APPLICATION AND FEATURES
2-1 Applications
This instrument is portable digital multimeter designed for
measurement of weak current circuits. It plays an important role in
circuitry analysis by using additional functions as well as
measurements of small type communication equipment, electrical
home appliance, lighting voltage and batteries of various type.
2-2 Features
The instrument meets the requirements to Safety Standard IEC
61010.
The main unit case and the circuit board are made of fire
retarding materials.
Fuse protects the current function.
500,000 counts in DCV and 999,999 counts in Hz range
Fast Response Digit: 5 times/sec., Bargraph: 60 times /sec.
Frequency measurement with 5 selectable sensitivity (Sine
RMS)
Capacitance measurement ranges are 50.00nF to 9999µF.
dBm, Duty ratio, %4-20mA measurement
0.01Ω of resistance and 0.01mV of AC/DC resolution
AC coupling True RMS / AC+DC coupling True RMS
MAX/MIN Recording through Auto range
MAX/MIN Capture (Peak hold 0.8ms in duration) through Auto
range
Relative measurement through Auto range
RS-232C interface
