5-7-2 Clamp probe: CL-22AD
1) Applications
ACA: It is suitable for measurement of alternating current in
electric equipment and power supplies.
DCA: An electric current of electric circuit of a car, and a
consumption electric current of direct current apparatus
are measured.
2) Measuring ranges
ACA: 2 ranges for 20A, 200A
DCA: 2 ranges for 20A, 200A
3) Measurement procedure
Connect the black plug to COM measuring terminal, and the
red plug to
V measuring terminal.
Set the function to 'V ' or 'V '.
Press the "RANGE" button to hold the 5V range.
Select either 20A or 200A by selector knob of clamp meter.
The zero point varies when the DCA is measured, so be
sure to check that the multimeter indicates zero. If not
zero, adjust the indication to the zero point by turning the
Zero adjuster (0ADJ).
Open the clamp part, have electric wire (one line) clamped,
and close the clamp part completely.
Read the value on the display. *2
After measurement, open the clamp part, and release clamp
probe from the electric wire.
*2: Read the value on the display as follows
Measuring range Multiplier Unit
20A x100 A
200A x1000 A
—
28
—
* Please do not use it in 500,000 counts.
* The effective digits indication is "0.000".
