5-7-4 Temperature probe: T300-PC
1) Applications
To measure temperature from -50 to 300 .
2) Measuring ranges
Range of -50 to 30
3) Measurement procedure
Connect the black plug to COM measuring terminal and the
red plug to Ω measuring terminal.
Set the function to 'Ω/ ' and select 'Ω' by pressing the
"
SELECT" button.
Press the "RANGE" button to hold the 5kΩ range.
Apply the sensor to an object to measure.
Read the value on the display. *4
After measurement, release the sensor from the object
measured.
*4: The value on the display of DMM shows a resistance
value indicate. Please read the value of measuring window
of PC Link.
—
