D-1034-143a PC5000（E）
DRAWING No. PC5000a 07-0812 2040 6010
Pollution degree:
2
E.M.C.:
Meets EN61326-1: 2006
Power Consumption:
42mW Typical/0.6mW Typical (Auto Power off)
Dimension:
179(H) x 87(W) x 55(D) mm with holster
Weight:
320 g, 460 g with holster
Accessories:
Test leads (TL-82), Alligator clip (CL-13), Holster (H-50),
Instruction manual
Optional Accessories:
RS232 cable: KB-RS2
Software: PC Link, PC Link Plus
Temperature Probe: T-300PC (Platinic thin film)
Clamp Probe: CL-20D, CL-22AD, and CL33DC
OVERVOLTAGE CATEGORY
• Equipment of CAT
is equipment for connection to circuits
in which measures are taken to limit the transient
overvoltages to an appropriate low level.
Note: Examples include protected electronic circuits.
• Equipment of CAT is energy-consuming equipment to be
supplied from the fixed installation.
Note: Examples include household, office, and laboratory
appliances.
• Equipment of CAT is equipment in fixed installations.
Note: Examples include switches in the fixed installation and
some equipment for industrial use with permanent
connection to the fixed installation.
• Equipment of CAT is for use at the origin of the installation.
Note: Examples include electricity meters and primary over-
current protection equipment.
—
36
—
