Sanyo C2462R - Outdoor Unit

– 14 –
SM830092
3. DIMENSIONAL DATA
(2) Outdoor Unit: C2462R, CL2462R
13-3/8
36-5/8
6-23/32
25-31/32
37
4-3/8
14-31/32
16-7/8
18-1/16
25/323/4
15-15/16
Dimension : inch
Hole for anchor bolt (4-R1/4)
Refrigerant tube joint (narrow tube)
Flare connection 3/8 in (9.52 mm)
Refrigerant tube joint (wide tube)
Flare connection 3/4 in (19.05 mm)
Refrigerant tubing inlet
Power supply inlet
1/21/2
1/2
1/2
5
5
4
4
