Sanyo C2462R - Major Component Specifications; (A) Indoor Unit

– 7 –
SM830092
2. SPECIFICATIONS
(2) Major Component Specifications
(A) Indoor Unit
MODEL No. KS2462R
Source 230 - 208 V / 1 phase / 60 Hz
Remote controller (Accessory) RCS - 1PS4U - G
Controller P. C. B Ass'y CR - KS2462R
Control circuit fuse 250 V, 3 A
Fan
Type Cross-flow
Number ... Dia. and length in. (mm) 1 ... O.D. 4 (100), L33-3/8 (847)
Fan motor
Model KFG4X - 31B6P-S
Source 230 - 208 V / 1 phase / 60 Hz
No. of pole … r.p.m. (230 V, High) rpm 4 … 1,365
Nominal output W 30
Coil resistance Ω BRW - WHT : 161.2 , ORG - YEL : 26.9
(Ambient temperature 68 °F) WHT - VLT : 11.6 , YEL - BLK : 22.8
VLT - ORG : 68.7 , BLK - PNK : 115.2
Safety device Internal
Operating temperature Open °F 266 ± 9
Close °F 181 ± 27
Run capacitor VAC, µF 440 V , 1.5 µF
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows … Fins per inch 2 … 19.5
Face area ft.
2
(m
2
) 2.30 (0.214)
Flap Motor
Type Stepping motor
Model ... Q’ty MP24GA2 ... 2
Step angle 5.625 deg / step
Rating V DC 12 V
Coil resistance (Ambient temperature 77 °F) Ω 400 ± 7 %
