– 9 –
SM830092
2. SPECIFICATIONS
(2) Major Component Specifications
(B) Outdoor Unit
MODEL No. CL2462R
Source 230 - 208 V / 1 phase / 60 Hz
Controller P.C.B. Ass'y CR - CL2432 (Microprocessor)
Control circuit fuse 250 V, 3 A
Compressor Scroll (Hermetic)
Model ZP23K3E
Source 230 - 208 V / 1 phase / 60 Hz
Nominal output W 2,400
Compressor oil cc 1,120
Coil resistance (Ambient temperature 77 °F) Ω C – R : 0.885 , C – S : 1.773
Safety device Internal type
Overload relay models —
Operating temperature Open °F 284 ± 9
Close °F 156 189
Operating ampere (at 77 °F) A —
Run capacitor VAC, µF 400 V, 40 µF
Crank case heater V, W 230 V, 30 W
Refrigerant amount charged at shipment lbs. (kg) R410A : 6.6 (3)
High pressure switch ACB
-
1UB24W
Set pressure OFF MPa 4.15
ON MPa 3.15 ± 0.3
Fan Propeller
Number...diameter in. (mm) 1 ... 18 - 3/32 (460)
Fan speeds 3 (AUTO)
Fan motor
Model KFC6T - 91D6P
Source 230 - 208 V / 1 phase / 60 Hz
No. of pole ..... rpm (230 V, High) 6 ... 879
Nominal output W 110
Coil resistance Ω BRN – WHT : 67.14 , VLT – YEL : 11.42
(Ambient temperature 68 °F) WHT – VLT : 64.85 , YEL – PNK : 10.60
Safety device Internal
Operating temperature Open °F 248 ± 9
Close °F 171 ± 27
Run capacitor VAC, µF 440 V, 4 µF
Heat exchange
Coil Aluminum plate fin / Copper tube
Rows ..... Fins per inch 2 ... 14.1
Face area ft.
2
(m
2
) 8.72 (0.81)
+ 0
– 0.15
DATA SUBJECT TO CHANGE WITHOUT NOTICE
