8
Cooling unit parts
<MDF-C8V>
Item Specifications
Compressor
115V, 60Hz Type: C-2SN400L2W Compressor code: 807 780 22
220/230/240V,50Hz Type: C-2SN400L5W Compressor code: 807 780 25
Refrigerant oil Ze-NIUS32SA Charged q’ty: 280cc
Cooling system Forced air cooling
Condenser
Type Finless tube Cascade condenser
Condenser 8 columns x 2 lines Coil pipe W200 mm x 8 columns
Pre-condenser 7 columns x 1 line P290 mm
ʊ
Frame pipe
φ4.76 x T0.7 mm
ʊ
Evaporator
Type
φ7.94 x T0.7 mm
Tube on sheet (also used as interior)
Capillary tube
φ1.2
Resistance (PSI kg/cm
2
)
0.59 MpaG
Length (mm) 2000
Outer diameter (mm)
φ1.8
Refrigerant HFC mixed refrigerant: MU-N48(EU)/(DOT) Charged q’ty: 375+/-8 g
Dryer Dry core: D-SM032T Charged q’ty: 35g
Condensing fan
φ196 mm, 4 blades
Material: ABS
(115V, 60Hz) SE4-D041N1P Output: 4W
Condensing fan
motor
(220/230/240V, 50Hz) SE4-D041N5P Output: 4W
