SPECIFICATIONS
Name Ultra-Low Temperature Freezer
Model MDF-C8V
External dimensions W550 x D685 (+83)* x H945 (mm)
Internal dimensions W405 x D490 x H425 (mm)
Effective capacity 84 L
Exterior Painted steel
Interior Painted steel
Door Painted steel
Access port Diameter 17 mm, back side, bottom
Insulation
Cabinet; Rigid polyurethane foamed-in place and VIP(vacuum insulation panel)
Door; Rigid polyurethane foamed-in place
Compressor Hermetic rotary type, 400 W
Evaporator Tube on sheet type (also used as a inner cabinet)
Condenser Finless tube type
Refrigerant HFC mixed refrigerant
Temperature controller Microcomputer control system
Temperature display Digital display (setting range; between -55
o
C and -85
o
C)
Temperature sensor
Platinum resistance (Pt 1000Ω)
Temperature alarm High temp. alarm, Low temp. alarm, Remote alarm, Battery check
Remote alarm contact Allowable contact capacity: DC 30 V, 2 A
Battery Nickel-metal-hydride battery, DC 6 V, 1100 mAh, Automatic charge
Weight 64 kg
Accessories 1 set of key, 1 scraper
Optional component
Automatic temperature recorder (MTR-85H, MTR-G85)
Mounting kit for automatic temperature recorder MTR-85H (MDF-S3085)
Recorder sensor cover (MTR-C8)
Back-up system (CVK-UB4), Back-up mounting plate (MDF-UBK)
Inventory rack (IR-207C, IR-305C)
Note:
Design or specifications will be subject to change without notice.
* The value in the parenthesis means the dimension of projected area.
The battery for power failure alarm is an article for consumption. It is recommended that the battery will
be replaced about every 3 years.
