42
9
FREEZER COMPONENTS
1. Lock: By turning to 180 degree to clockwise with a key, the door can be locked.
2. Door: Top hinged type. To open the door, grip the handle.
3. Magnetic door gasket: Seals the door and prevents leakage of cold air.
4. Inner lid: Serves as a means of reducing cold air leakage when the door is open. Remove the frost
regularly.
5. Access port: Located on the back side and bottom. These are used for leading the measuring
cable from the freezing chamber to the outside. The bottom port is also used for passing the
temperature sensor.
6. Caster: 4 casters are provided for easy movement.
7. Leveling foot: Serves to adjust the height and to settle the frame evenly.
8. Intake air vent: Be careful not to block this.
9. Control panel: The temperature setting keys etc. are located. See page 10 for details.
10. Space for temperature recorder: An automatic temperature recorder (optional part) can be
attached here. See page 30 “Temperature recorder (option)”.
11. Battery switch (back side): Switch for battery used for power failure alarm. Always keep ON.
Turn the switch OFF when the unit is in no use for a long period (more than 1 month).
12. Remote alarm terminal (back side): Used to notify an alarm condition of the unit to remote location.
See page 19 for details.
13. Fixture (back side): A fixture is attached to the rear of the frame. Fix the frame to the wall with
this fixture and rope or chain.
