66
Appendix
Terminal : Mini DIN 8-PIN
1
2
3
4
5
8 7 6
SERVICE PORT CONNECTOR
Vcc
- Data
+ Data
Ground
1
2
3
4
USB CONNECTOR (Series B)
2
34
1
R X D
-----
-----
GND
RTS / CTS
GND
GND
Serial
1
2
3
4
5
6
7
8
COMPUTER INPUT/COMPONENT INPUT/MONITOR OUTPUT TERMINAL (ANALOG)
Terminal : Analog RGB (Mini D-sub 15 pin)
5
1
2
34
10
9 678
15
14
13
11
12
Configurations of Terminals
Red (R/Cr) Input / Output
Ground (Horiz.sync.)
Green (G/Y) Input / Output
-----
Blue (B/Cb) Input / Output
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
-----
Horiz. sync. Input/Output (Composite H/V sync.)
Ground (Vert.sync.)
-----
Ground / -----
Vert. sync.
-----
9
13
10
12
11
14
15
T X D
