Condenser lens adjustment ❍●
Relay lens adjustment ❍●
Contrast Adjustment
R-Contrast adjustment ●
G-Contrast adjustment ●
B-Contrast adjustment ●
Output voltage adjustment ●
+16 V adjustment ●
Video center adjustment ●
NRS adjustment ●
PC pedestal adjustment ●
Black level adjustment ●
PC gain adjustment ●
PC gamma shift adjustment ●
HDTV pedestal adjustment ●
HDTV A/D input adjustment ●
HDTV Gain adjustment ●
Video pedestal adjustment ●
Video A/D input adjustment ●
A/D offset adjustment ●
Video gain adjustment ●
Video gamma shift adjustment ●
Common center adjustment ● ●
White balance adjustment ❍ ❍
Disassembly / Replaced Parts
LCD/
Prism
Ass’y
Condenser
Lens
Polarized glass
RGB
Optical Adjustments
Electrical Adjustments
● : Adjustment necessary ❍ : Check necessary
Sub Power
Board
Main Board
Relay
Lens
■ Adjustments after Parts Replacement
Power
Board
To Next Page
