Bottom
Back
q Zoom Ring
w Infrared Remote Receiver
e Focus Ring
r Projection Lens
t Slide Shutter Lever
y Top Controls and Indicators
u Exhaust Vent
i
!4
!3
!2
!1
CAUTION
Hot air is exhausted from the exhaust
vents. Do not put heat-sensitive objects
near this side.
e r t y
Front
!0
o
q w
u
o o
!4
i Speaker
o Air Intake Vents
!0 Terminals and Connectors
!1 Power Cord Connector
!2 Lamp Cover
!3 Filter
!4 Adjustable Feet
✽ Kensington Security Slot
This slot is for a Kensington lock used to deter
theft of the projector.
* Kensington is a registered trademark of ACCO Brands
Corporation.
✽
Part Names and Functions
